8t 9t 10 Ton 20ton Empty Container Handler For Narrow Passages And
Limited Spaces
Battery power supply is selected. The working principle of this
type of electric flat carT is to provide power through the battery
and drive the flat car to move through the motor. The flat car is
equipped with on-board control buttons, which can control the flat
car to move forward, backward, stop, etc. The flat car is braked by
electromagnetic braking motor, which is stable, reliable, safe to
use and convenient for maintenance. In order to ensure the safety
of the flat car, emergency stop button is installed on the
operation button of the flat car, and audible and visual alarm
devices are installed at both ends of the flat car. The braking
system adopts electromagnetic brake, which has the function of
automatic braking after power loss. The brake can be released
manually to ensure that people can push.
Endurance: the transfer cart can run continuously for 4-5 hours.
Advantages of intelligent charger: installed inside the electrical
box, saving space, fast charging time, small size, automatic power
off.
Empty Container Handler Parameter:
| product name | industrial material transfer trolley cart |
| capacity | 20ton or customized |
| main material | steel, battery, electronics |
| size | 4000*3000*300mm or customized |
| powered by | lithium battery or lead acid battery |
| working time | 5-6 hours |
| charging time | 7-8 hours |
| control | remote control,forward, back, left ,right, emergency stop. |
| main parts | motor, 4 wheels, lithium or lead acid battery, electrical control
box |
| Wheel | 4,Polyurethane or rubber |
| IP grade | IP 44 or IP54(outdoor) |
| type | railless. with rail can be customized |
| guaranteed | 1 year |
| color | customized. |
| certificate | CE& ISO9001:2015 |
Empty Container Handler Photos
Lithium battery powered
Our transfer cart is usually powered by a lithium battery. Compared
to traditional lead-acid batteries, lithium batteries have a
shorter charging time (2 hours) and a longer life span of four to
five years.
Transfer cart frame
It is a box-type structure, Q235-B cast steel is refined, it is not
easy to be deformed, and the appearance is beautiful and durable.
,
Infrared induction
When the car encounters people or obstacles during the running, it
will be detected in advance and stop running.
Remote control Our transfer car comes standard with wireless remote control and
wired handle. Wireless remote control is more convenient. Can be
controlled from a distance. Dual remote control configuration, when
the wireless remote control is damaged, you can also use the wired
handle, which will not delay production.
Custom production design
1. Professional designers can provide reasonable solutions
according to your actual needs; We’ve supplied 5000+ cases to
customers all over the world.
