Make Full Use Of Plant Space Double Girder European Overhead Crane
Improve Production Efficiency
Introduction:
The double-girder European crane has a compact design, light
weight, small wheel pressure, and even load distribution, which can
save customers considerable investment and greatly improve the
effective working space. The double-girder European crane is not
only safe and reliable, but also ergonomically designed, easy to
operate, safe and comfortable, and makes material transportation
more convenient and efficient. There are many dosing options for
customers to choose from, such as hoisting frequency conversion,
hoist double, remote control, etc., to meet the needs of various
working conditions or logistics transportation.
Advantages of double girder European crane:
compact design
The advanced design concept makes the European double-girder crane
have a lightweight structure and excellent performance, and at the
same time reduces the operating limit distance of the hook to the
greatest extent, effectively improves the space utilization rate,
and also enables customers to reduce plant investment costs. The
use of European double-girder cranes will bring more lucrative
investment returns to your investment.
Fast and smooth loading
The standard configuration of the double-girder European crane is
that both the trolley and the trolley are frequency-converted,
which makes the driving run smoothly, the positioning is fast, and
the swing of the loaded object is effectively solved. Dyna stepless
frequency conversion control system is a patented product of
European double-girder cranes. It is specially designed for crane
applications. It has the characteristics of stable braking,
accurate positioning, reliable performance and high efficiency.
Safer, more reliable, with maintenance-free design
The European-style double-girder crane adopts advanced technology
from design selection to manufacturing process, especially in
frequent operations. The perfect braking system greatly improves
the safety and reliability. The high-performance brake is designed
with dust-proof, can be adjusted automatically, and has a safe
service life of more than 1 million times. The moving gear is
processed accurately, and the tooth surface is hardened and ground,
which can ensure the long-term trouble-free operation of the
European crane.
Better performance
European double-girder cranes are important logistics equipment,
and the losses caused by production stoppages or failures are
immeasurable. European-style double-girder cranes will be your best
choice in the field of logistics, adhering to the consistent good
quality of products.
Technical Parameter:
| Technical Specifications |
|
| Lifting Capacity | Span | Lifting | Work Duty | Main Lifting | Vice Lifting | Trolley Traveling | Crane Traveling | Track |
| Height | Speed | Speed | Speed | Speed |
| | | | |
| t | m | m | | m/min | m/min | m/min | m/min | |
| 5 | 13.5~19.5 | 18 | A5 | 0.84~8.4 | | 3.4~34 | 5.1~51 | 38kg |
| 22.5~31.5 | 5~50 |
| 5 | 13.5~19.5 | 18 | A5 | 0.78~7.8 | | 3~30 | 5~50 | 38kg |
| 22.5~31.5 | 5.2~52 |
| 16/5 | 13.5~19.5 | 18/18 | A5 | 0.76~7.6 | 0.84~8.4 | 3.5~35 | 5.1~51 | 43kg |
| 22.5~31.5 | 5.2~52 |
| 20/5 | 13.5~19.5 | 18/18 | A5 | 0.6~6 | 0.84~8.4 | 3.5~35 | 5.1~51 | 43kg |
| 22.5~31.5 | 5.2~52 |
| 32/5 | 13.5~19.5 | 18/18 | A5 | 0.52~5.2 | 0.84~8.4 | 3.1~31 | 5.1~51 | 43kg |
| 22.5~31.5 | 5.2~52 |
| Oct-50 | 13.5~19.5 | 18/18 | A5 | 0.43~3.9 | 0.78~7.8 | 3.6~36 | 4.8~48 | 43kg |
| 22.5~31.5 | 5.4~54 |
| Notes: Customizable |
Application:
Double girder overhead crane is an important tool and equipment to
realize mechanization and automation of production process in
modern industrial production and lifting and transportation.
Therefore, double-girder overhead cranes are widely used in indoor
and outdoor industrial and mining enterprises, iron and steel
chemical industry, railway transportation, port terminals and
logistics turnover departments and places.
