High Efficiency Workshop Electric Wire Rope Hoists , Electric
Lifting Hoist
Brief Introduction
Electric hoist is a kind of special lifting equipment, which is
installed on overhead cranes and gantry cranes. Electric hoists
have the characteristics of small size, light weight, simple
operation and convenient use. They are used in industrial and
mining enterprises, storage, docks and other places.
The electric hoist has a compact structure, and the electric hoist
whose motor axis is perpendicular to the reel axis adopts a worm
gear transmission. The disadvantages are: large length, large
width, clumsy structure, low mechanical efficiency, and difficult
processing. The hydraulic system is dual-controlled, and the
pressure relief valve and magnetic contact pressure gauge can
precisely control the pressure. The electrical control department
adopts low voltage control, which increases the safety of the
control system.
Technical parameter
Type | |
Capacity (t) | 0.25 | 0.5 | 1 | 2 | 3 | 5 | 10 | 16 |
Lifting Height (m) | 3~9 | 6~12 | 6~30 | 6~30 | 6~30 | 6~30 | 9~30 | 9~30 |
Lifting Speed (m/min) | | 7(0.7/7) | 3.5(0.35/3.5) |
Traveling Speed (m/min) | 20 | 20/30 | 18 |
Rail | 10-20b | 16-28b | 20a-32c | 25a-50b | 32b-50b | 32b-63c |
Work Duty | |
Power | |
1. Reducer: adopt third-class dead axel helical gear transmission
structure gear and geaaxel are made of heat treated alloy steel
2. Button Switch: easy to operate, safey for operator, both remote
control and pendant control are available.
3. Motor: three-phase asynchronous induction motor, durable and
powerful. Insulation grade is F.
4. Protection grade: IP54, work grade: M3
5. Over load limit is available. Hook is widen and thicken
6. Power-Off protection, Emergency stop system.
7. Low noise, soft starting and stopping
8. Safe and reliable operation
9. One year warranty for whole machines
10. Providing free quick-wear part
11. Low charge for continue maintenance when warranty is expired
12. Exclusive engineer support at any time.
13. Highly professional training to end-users.
Photo:
